Additional information
| Weight | 0,23 kg |
|---|---|
| Reference number | AB4630131160, 0639394, 639394, 1761990, 236950, 8283732000, A0012609157, 99708458325, 9628S4630131160, T64172M36A02, 160187, 4782794, U403003797, 02564591, 04782794, 04604222, 61232936, 4782794, 30416, 0478 2794, 4604222, S463-013-116-0, 20790140, 82837320000, GT070239, 249049, 639395, 5029262, A05110520, 4630131160, 6300-4630131160, 81156106004, 81521856009, 81521856014, 81521856041, 88521636206, 81521859014, 4630131160, 236950, 0004340501, 0004340801, 0004341001, 0004341101, 0004342101, 0004342301, 0004342401, 0004342901, 0004343001, 0004343101, 0007631252, 0012609157, A0012609157, S4630131160, 110246400, 11017347, 1102462544401, 1505075, S463-013-116-0, 5021170181, 5000786419, 0340178, 340176, 340178, 1934904, 82837320000, 13761, 96925200, 20190478, WAB4630131160 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuating range | 0.22 in |
| Actuation | Push |
| Calculated Volume (dm³) | 0.18217 |
| Comments | With hex.nut : M 26×1.5 |
| Exhaust | M12 x 1.5 |
| Handle length | 1.85 in |
| Max. operating pressure | 145.0 psi |
| Mounting | M26 x 1.5 |
| Nominal diameter | 4.0 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port thread 3 | M12 x 1.5 |
| Stroke | 0.22 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 3/2 |
| Size (mm x mm x mm) | 102 x 47 x 38 |
| UPC | 193133442394 |
| Weight (kg) | 0.23 |
| Weight (lb) | 0.50706 |
| GTIN | 04057875212348 |
| Brand | WABCO |
