Additional information
| Weight | 6,85 kg |
|---|---|
| Reference number | 1505469 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 12.2102 |
| Max. operating pressure | 145.04 / 116.03 psi |
| Mounting | M48 x 2 |
| Output force 3 | 1573.66 lbf |
| Output force M | 1146.53 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port threads | M22 x 1.5 |
| Release pressure | 73.97 psi |
| Return-spring force | 33.72 lbf |
| Stroke | 2.09 / 2.09 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 1.3 in |
| Total lenght | 13.19 in |
| Type | 12/16 |
| Type of operation | Wedge |
| Size (mm x mm x mm) | 425 x 169 x 170 |
| UPC | 193133252177 |
| Weight (kg) | 6.85 |
| Weight (lb) | 15.102 |
| GTIN | 04057875169307 |
| Brand | WABCO |
