Additional information
| Weight | 9,8 kg |
|---|---|
| Reference number | 884491, 0884493, 2100382, 2100383, 19123, 19124, 19125, 500590358, 4112029, 10218885, 11080017, A0244200918, A0244201018, 68323862, 68324406, 68324407, 1664248, 1664252, 17155, 17156, 03197932, 03197933, 20386416, 20401590, 20401591, 20466070, 20466073, 3197932, 3197933, 1935452, 2079867, 8500253, 19920112, 20386381, 20386416, 20401590, 20401591, 20409105, 20466070, 20466071, 20466072, 20466073, 3197932, 3197933, 3987614, 8113459, 85000253, 2038641, 20522028, 2052203, 20721846, 20721847, 21283629, 2159622, 21596226, 3197032 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 16.38 |
| Connection Port / Fitting | M16×1.5 |
| Connection Specification | JED-152 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 123.28 psi |
| Output force service brake | 9.0 kN |
| Output force spring brake | 5.5-10 kN |
| Port thread 11 | M16 x 1.5 JED – 152, Voss 232 NG 12 |
| Port: working pressure [p emax.] | <strong>11</strong>: 10 bar (13 bar), <span><strong>12</strong>: 8.5 bar (11 bar)</span> |
| ProVia warranty | 1 year |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 71.07 psi |
| Return-spring force | 49.46 lbf |
| Technical specification | AM specification |
| Temperature range | -40°F to +176°F |
| Total lenght | 11.26 in |
| Type | 24/24 |
| Type of operation | Disc |
| GTIN | 04057877001933 |
| Size (mm x mm x mm) | 400 x 195 x 210 |
| UPC | 193134005352 |
| Weight (kg) | 9.8 |
| Weight (lb) | 21.61 |
| Stroke | 2.56 / 2.56 in |
| Brand | WABCO |
