Additional information
| Weight | 9,847 kg |
|---|---|
| Reference number | 1527168R, 1527601R, 1528230R, 68325461, 68325530, 68325531, 68325581, 68325582, 1527168R, 1527601R, 20533213, 20573922, 20573923, 20809444, 20809445, 21283616, 21283617, 21283618, 21326197, 21326198, 21326201, 21326202, 21596228, 21596229, 22080447, 22080448, 24425719, 24425720, 7420522028, 7420522029, 7420533213, 7420573922, 7420573923, 7420721845, 7420809445, 7421283616, 7421283617, 7421283618, 7421326201, 7421326202, 7421401943, 7421401944, 7421596228, 7421596229, 7422080447, 7422080448, 7424425719, 7424425720, 7420809444, 1935462, 8500253, 33185, V21596226, V21596227, 20522028, 20522029, 20522030, 20522031, 20721845, 20721846, 20721847, 20742392, 20742393, 20742394, 20844352, 20844353, 21283628, 21283629, 21323797, 21326199, 21326200, 21326203, 21423487, 21444612, 21596226, 21596227, 21752714, 21752715, 21869990, 22080445, 22080446, 22273774, 22273775, 85000466, 85000607, 85000635, 85003834, 20409105, 20466070, 20466071, 20466072, 20466073, 2052203, 2132619, 21326197, 21326198, 213262, 2142348, 2159622, 3197932, 3197933, 3987614, 8113459, 85000253 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 14.44 |
| Connection port / fitting | M16×1.5 |
| Connection specification | JED-464-0 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 123.28 psi |
| Output force service brake | 9.0 kN |
| Output force spring brake | 5.5-10 kN |
| Port thread 11 | M16 x 1.5 JED – 152, M16 x 1.5 JED – 464-0 |
| Port: working pressure [p emax.] | <strong>11</strong>: 10 bar (13 bar), <span><strong>12</strong>: 8.5 bar (11 bar)</span> |
| ProVia warranty | 1 year |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 71.07 psi |
| Return-spring force | 49.46 lbf |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.26 in |
| Type | 24/24 |
| Type of operation | Disc |
| GTIN | 04057877001957 |
| Size (mm x mm x mm) | 380 x 200 x 190 |
| UPC | 193134005383 |
| Weight (kg) | 9.847 |
| Weight (lb) | 21.71 |
| Stroke | 2.56 / 2.56 in |
| Brand | WABCO |
