Additional information
| Weight | 12,73 kg |
|---|---|
| Reference number | A0194209918, A0204200018, A0194208118, A0194208218 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Bolt lengths | 1.56 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 25.09 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 123.28 psi |
| Port thread 11 | VOSS 232 NG 12 |
| Port thread 12 | Voss 232 NG 12 |
| ProVia warranty | 1 year |
| Push-rod length | 1.46 in |
| Release pressure | 73.97 psi |
| Stroke | 2.56 / 2.56 in |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.94 in |
| Type | 30/30 |
| Version | Sealing washer |
| Yoke | Welded |
| GTIN | 04057877004132 |
| Size (mm x mm x mm) | 410 x 240 x 255 |
| UPC | 193134004843 |
| Weight (kg) | 12.73 |
| Weight (lb) | 28.06 |
| Type of operation | Cam |
| Brand | WABCO |
