Additional information
| Weight | 11 kg |
|---|---|
| Reference number | 3276-X-1142, 3276-Y-1143, 21994025, 5010216959, 5010251265, 5010260960, 7421994025, 20533210, 20533211, 21569207, 21988037, 21994025, 21994026, 1079945, 20466200, 20466201, 3986630 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Bolt lengths | 1.56 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 34.12 |
| Clevis pin | 0.55 in |
| Connection port / fitting | M16×1.5 |
| Connection specification | JED-464-0 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 123.28 psi |
| Output force service brake | 12.1 kN |
| Output force spring brake | 7.5-10 kN |
| Port thread 11 | M16 x 1.5 JED-464-0 |
| Port: working pressure [p emax.] | <strong>11</strong>: 10 bar (13 bar), <span><strong>12</strong>: 8.5 bar (11 bar)</span> |
| ProVia warranty | 1 year |
| Push-rod length | 11.69 in |
| Push-rod length without yoke | 9.72 in |
| Push-rod thread | M16 x 1.5 |
| Stroke | 2.56 / 2.56 in |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.87 in |
| Type | 27/24 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Screwed |
| GTIN | 04057877002749 |
| Size (mm x mm x mm) | 650 x 250 x 210 |
| UPC | 193134004836 |
| Weight (kg) | 11 |
| Weight (lb) | 24.25 |
| Release pressure | 71.07 psi |
| Brand | WABCO |
