Additional information
| Weight | 10,41 kg |
|---|---|
| Reference number | 0867215R, 1487296, 1487296R, 1519158, 1523549, 1523549R, 867215, 0867215, 1446705R, 1506655R, A0234204918, 84233, 6500690, 571538008, 0005680012, 81504106608, 81504106609, 81504106610, 2V5615331E, 2V5615332E, 81504106540, 81504106551, 81504106552, 81504106618, 81504106619, 81504106620, 81504106684, 81504109540, 81504109551, 81504109552, 85504106002, 81504106608, 81504106609, 81504106610, 0867215R, 1487296R, 5021170336, 1935401, 1935471, 2089719, 1020765, 1020766, V1573854, 25509640 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Bolt lengths | 1.56 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 28.4 |
| Clevis pin | 0.55 in |
| Connection port / fitting | M22×1.5/M22×1.5 |
| Connection specification | JED-388-0 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 123.28 psi |
| Output force service brake | 9.0 kN |
| Output force spring brake | 6.8-11 kN |
| Port thread 11 | M22 x 1.5 JED-388-0 |
| Port: working pressure [p emax.] | <strong>11</strong>: 10 bar (13 bar), <span><strong>12</strong>: 8.5 bar (11 bar)</span> |
| ProVia warranty | 1 year |
| Push-rod length | 11.42 in |
| Push-rod length + yoke (middle of yoke) | 11.42 in |
| Push-rod length without yoke | 10.14 in |
| Release pressure | 79.77 psi |
| Stroke | 2.24 / 2.24 in |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.43 in |
| Type | 24/24 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Screwed |
| GTIN | 04057877001971 |
| Size (mm x mm x mm) | 650 x 230 x 190 |
| UPC | 193134005321 |
| Weight (kg) | 10.41 |
| Weight (lb) | 22.95 |
| Push-rod thread | M16 x 1.5 |
| Brand | WABCO |
