Additional information
| Weight | 4 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.38 in |
| Bolt threads | M12 x 1.5 |
| Calculated Volume (dm³) | 0 |
| Clevis pin | 0.49 in |
| Comments | M251600 |
| Distance between bolts | 3 in |
| Max. operating pressure | 145.04 psi |
| Output force M | 1348.85 lbf |
| Port thread 11 | M22 x 1.5 |
| Push-rod length | 2.83 in |
| Push-rod thread | M14 x 1.50 |
| Return-spring force | 32.60 lbf |
| Stroke | 2.09 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 8.54 in |
| Type of operation | Cam |
| Version | With boot |
| Yoke | With |
| GTIN | 04057875002239 |
| UPC | 193133047766 |
| Weight (kg) | 4 |
| Weight (lb) | 8.8185 |
| Type | 12/12 |
| Brand | WABCO |
