Additional information
| Weight | 0,436 kg |
|---|---|
| Reference number | A0009974612, TDAS4721700020, S4721700020, TDAS4721700020, 6300-4721700020, S4721700020, S4721700020, TDAS4721700020, WAB4721700020 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.3388 |
| Electrical connection | TYCO HDSCS Cod. A C-114-18739-1 (INDEX C) |
| Exhaust | 4.0 mm |
| Max. operating pressure | 147.94 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.16 in |
| Port thread 1 | V16 x 1.5 JED-388 |
| Port thread 2 | V16 x 1.5 JED – 388 |
| Protection class | IP 6K6K / IP 6K9K |
| Rated current | 1410 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally Closed |
| Voltage | 12 V |
| GTIN | 04057875320418 |
| Size (mm x mm x mm) | 70 x 121 x 40 |
| UPC | 193133443001 |
| Weight (lb) | 0.96121 |
| Weight (kg) | 0.436 |
| Brand | WABCO |
