Additional information
| Weight | 0,538 kg |
|---|---|
| Reference number | A0049979236, TDAS4721707000, 42546417, 0049979236, 4833404, S4721707000, 0049979236, A0049979236, 4833404, S4721707000, S4721707000, 2089742, 10558451, 20276563 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.271 |
| Electrical connection | M27 x 1 |
| Exhaust | 4.0 mm |
| Max. operating pressure | 188.5 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.16 in |
| Nominal diameter | 4.0 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Protection class | IP 6K9K / IP 6K7 |
| Rated current | 690 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally closed |
| Voltage | 24 V |
| GTIN | 04057875218104 |
| UPC | 193133443056 |
| Weight (kg) | 0.538 |
| Weight (lb) | 1.1861 |
| Size (mm x mm x mm) | 61 x 111 x 40 |
| Brand | WABCO |
