Additional information
| Weight | 0,602 kg |
|---|---|
| Reference number | 6537092, 1639096, 0644431, 4834687, 98444992, 5006305805, 42546462, 5006305805, 9472128908, E4420001031, 0644431, 4834687, 98444992, S472-171-000-0, 21145210024, 6300-4721710000, 0009971012, A0009971012, S4721710000, S472-171-000-0, 4425007200, 2089743, 1102730300, 21145210024, 10652938, WAB4721710000, 1013101 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.37668 |
| Electrical connection | M27 x 1 |
| Exhaust | 2.2 mm |
| Max. operating pressure | 188.5 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.09 in |
| Nominal diameter | 2.2 mm |
| Port thread 1 | M14 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port thread 3 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Protection class | IP 6K9K / IP 6K7 |
| Rated current | 410 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally open |
| Voltage | 24 V |
| Size (mm x mm x mm) | 129 x 73 x 40 |
| UPC | 193133443179 |
| Weight (kg) | 0.602 |
| Weight (lb) | 1.3272 |
| GTIN | 7895851026902 |
| Brand | WABCO |
