Additional information
| Weight | 0,534 kg |
|---|---|
| Reference number | 1315508, 504088165, 6503411, 1315508, 1788960, 41196419, 1196419, 1013215 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.30736 |
| Electrical connection | Bayonet DIN 72 585 A1-2.1-Sn/K1 |
| Exhaust | 2.2 mm |
| Max. operating pressure | 232.1 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.09 in |
| Nominal diameter | 2.2 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port thread 3 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Protection class | IP 6K9K / IP 6K7 |
| Rated current | 410 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally open |
| Voltage | 24 V |
| Size (mm x mm x mm) | 113 x 68 x 40 |
| UPC | 193133311072 |
| Weight (kg) | 0.534 |
| Weight (lb) | 1.1773 |
| GTIN | 04057875218265 |
| Brand | WABCO |
