Additional information
| Weight | 0,541 kg |
|---|---|
| Reference number | 1506157, 0049978936, 0644431, A0049978936, 053669, MO58830, M058830, 41016827, S4721717000, 99114710043, 0049978936, A0049978936, 0644431, S4721717000, 11017383, 1250689, 1159110, S4721717000, 1934960, 050804, 50804, INS0120012, 10532891 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.28272 |
| Electrical connection | M27 x 1 |
| Exhaust | 2.2 mm |
| Max. operating pressure | 188.5 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.09 in |
| Nominal diameter | 2.2 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port thread 3 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Protection class | IP 6K9K / IP 6K7 |
| Rated current | 410 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally open |
| Voltage | 24 V |
| Size (mm x mm x mm) | 114 x 62 x 40 |
| UPC | 193133443186 |
| Weight (kg) | 0.541 |
| Weight (lb) | 1.1927 |
| GTIN | 04057875218289 |
| Brand | WABCO |
