Additional information
| Weight | 0,535 kg |
|---|---|
| Reference number | 1330025, 1197581, 1315509, 41026587, 4255089, 41026587, 41026587, 00123323, 123323, 1197581, 1315509, 1330025, 4255089, 1716010261, 1330025, 1330025, 5010347978, 1738496, 41197581 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.2852 |
| Electrical connection | Bayonet DIN 72 585 A1-2.1-Sn/K1 |
| Exhaust | 3.0 mm |
| Max. operating pressure | 159.54 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.09 in |
| Nominal diameter | 2.2 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Protection class | IP 6K6 / IP 6K9K |
| Rated current | 410 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally closed |
| Voltage | 24 V |
| GTIN | 04057875218364 |
| UPC | 193133310273 |
| Weight (kg) | 0.535 |
| Weight (lb) | 1.1795 |
| Size (mm x mm x mm) | 115 x 40 x 62 |
| Brand | WABCO |
