Additional information
| Weight | 0,54 kg |
|---|---|
| Reference number | 1285559, 1524866, 1296722, 5006220487, 41016821, 5006220487, 42542853, 98451915, 4721706040, 84521606032, 84526106032, 4721706040, 1296722, 110254009, 11017381, 1934957, 1102540090 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.299 |
| Electrical connection | Bayonet |
| Exhaust | 4.0 mm |
| Max. operating pressure | 188.5 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.16 in |
| Nominal diameter | 4.0 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Protection class | IP 6K6 / IP 6K9K |
| Rated current | 690 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally closed |
| Voltage | 24 V |
| GTIN | 04057875218074 |
| UPC | 193133310266 |
| Weight (kg) | 0.54 |
| Weight (lb) | 1.1905 |
| Size (mm x mm x mm) | 115 x 65 x 40 |
| Brand | WABCO |
