Additional information
| Weight | 0,543 kg |
|---|---|
| Reference number | 1518103, W20709.02900.01W, 17YNA07011, 235600040, 81521606125, 81521606125, 1518103, 350601105A |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.28993 |
| Electrical connection | Bayonet DIN 72 585 A1-3.2-Sn/K1 |
| Exhaust | 4.0 mm |
| Max. operating pressure | 188.5 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.16 in |
| Nominal diameter | 4.0 mm |
| Port thread 1 | M10 x 1 |
| Port thread 2 | M12 x 1.5 |
| Port thread 3 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Protection class | IP 6K9K / IP 6K7 |
| Rated current | 690 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally open |
| Voltage | 24 V |
| Size (mm x mm x mm) | 39 x 118 x 63 |
| UPC | 193133311164 |
| Weight (kg) | 0.543 |
| Weight (lb) | 1.1971 |
| GTIN | 04057875218531 |
| Brand | WABCO |
