Additional information
| Weight | 0,554 kg |
|---|---|
| Reference number | S4721707900, S4721707900, S4721707900, 10630765 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.34748 |
| Cooling | Air |
| Electrical connection | M27 x 1 |
| Exhaust | 4.0 mm |
| Max. operating pressure | 188.5 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.16 in |
| Nominal diameter | 4.0 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 2 | 14.5 mm |
| Protection class | IP 6K6 / IP 6K9K |
| Rated current | 690 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally closed |
| Voltage | 24 V |
| GTIN | 04057875218111 |
| UPC | 193133443063 |
| Weight (kg) | 0.554 |
| Weight (lb) | 1.2214 |
| Size (mm x mm x mm) | 119 x 73 x 40 |
| Brand | WABCO |
