Additional information
| Weight | 0,544 kg |
|---|---|
| Reference number | 1518906, 41016822, 41016824, 41016822, 41003961, 4101682, 81521606073, 81521606094, 81521606140, 81521606140, 4721737040, 1158009, 41003961, 4101682, 81521606073, 81521606094, 81521606140 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.28272 |
| Electrical connection | Bayonet |
| Exhaust | 4.0 mm |
| Max. operating pressure | 188.5 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.16 in |
| Nominal diameter | 4.0 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port thread 3 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Protection class | IP 6K9K / IP 6K7 |
| Rated current | 690 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally open |
| Voltage | 24 V |
| Size (mm x mm x mm) | 114 x 62 x 40 |
| UPC | 193133311171 |
| Weight (kg) | 0.544 |
| Weight (lb) | 1.1993 |
| GTIN | 04057875218586 |
| Brand | WABCO |
