Additional information
| Weight | 0,522 kg |
|---|---|
| Reference number | 1518898, 81521606115, 81521606117, 81521606122, 81521609115, 81521606116, 81521606142, 81521606143, 81521606115, 2089735, 69497 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.27972 |
| Electrical connection | Bayonet DIN 72 585 A1-3.2-Sn/K1 |
| Exhaust | 3.0 mm |
| Max. operating pressure | 159.54 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.09 in |
| Nominal diameter | 2.2 mm |
| Port thread 1 | 3x M12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Protection class | IP 6K6 / IP 6K9K |
| Rated current | 410 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally closed |
| Voltage | 24 V |
| GTIN | 04057875217671 |
| UPC | 193133310754 |
| Weight (kg) | 0.522 |
| Weight (lb) | 1.1508 |
| Size (mm x mm x mm) | 40 x 111 x 63 |
| Brand | WABCO |
