Additional information
| Weight | 0,513 kg |
|---|---|
| Reference number | 875532660, 1504981, A0014317506, TDAS4721231070, 04850642, S472-123-107-0, S4721231070, 6300-4721231070, 0014317506, A0014317506, 0039971736, S4721231070, 1504981, S472-123-107-0, 7700063843, TDAS4721231070, WAB4721231070 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.28405 |
| Electrical connection | M27 x 1 |
| Exhaust | 3.0 mm |
| Max. operating pressure | 145.0 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.09 in |
| Nominal diameter | 2.2 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Protection class | IP 68 |
| Rated current | 860 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally closed |
| Voltage | 12 V |
| GTIN | 04057875217879 |
| UPC | 193133442998 |
| Weight (kg) | 0.513 |
| Weight (lb) | 1.131 |
| Size (mm x mm x mm) | 115 x 65 x 38 |
| Brand | WABCO |
