Additional information
| Weight | 0,365 kg |
|---|---|
| Reference number | 42568328, ANR4869, 30023285 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.24592 |
| Electrical connection | 2x 2-Pole AMP 963 040-3 |
| Max. operating pressure | 203.1 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.04 in |
| Port thread 11 | VOSS 203 Ø 0.16 in |
| Port thread 12 | VOSS 203 Ø 0.16 in |
| Port thread 21 | VOSS 203 Ø 0.16 in |
| Port thread 22 | VOSS 203 Ø 0.16 in |
| Protection class | IP 68 |
| Rated current | 750 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 2x 2/2 |
| Voltage | 12 V |
| GTIN | 04057875219477 |
| Size (mm x mm x mm) | 58 x 80 x 53 |
| Weight (kg) | 0.365 |
| Weight (lb) | 0.80469 |
| UPC | 193133312055 |
| Brand | WABCO |
