Additional information
| Weight | 0,75 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.7626 |
| Distance between holes | 2.8×0.79 in |
| Electrical connection | Bayonet ISO 15 170 A1-3.1-Sn/K1 |
| Exhaust | Integrated silencer |
| Max. operating pressure | 159.5 psi |
| Mounting | 2x Ø 8.5 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Protection class | IP 67 / IP 69K |
| Rated current | 2220 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 12 V |
| GTIN | 04057876097364 |
| Size (mm x mm x mm) | 110 x 59 x 117.5 |
| UPC | 193133520047 |
| Weight (lb) | 1.653 |
| Weight (kg) | 0.75 |
| Brand | WABCO |
