Additional information
| Weight | 0,498 kg |
|---|---|
| Reference number | A0064291844, A0064291844 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.4692 |
| Distance between holes | 2.8×0.79 in |
| Electrical connection | TYCO HDSCS 4x 2.8 CODING A |
| Exhaust | Flap |
| Max. operating pressure | 159.5 psi |
| Mounting | 2x Ø 0,33 in |
| Port thread 1 | M22 x 1.5 JED-388-4 |
| Port thread 2 | M22 x 1.5 JED – 388-4 |
| Protection class | IP 6K6K / IP 6K9K |
| Rated current | 1560 mA |
| Technical specification | OE specification |
| Temperature range | -40°F to +176°F |
| Voltage | 24 V |
| GTIN | 04057875328193 |
| Size (mm x mm x mm) | 120 x 46 x 85 |
| UPC | 193133406730 |
| Weight (lb) | 1.098 |
| Weight (kg) | 0.498 |
| Brand | WABCO |
