Additional information
| Weight | 0,684 kg |
|---|---|
| Reference number | L0356D02011A0, L0356D02013A0 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.7442 |
| Distance between holes | 2.8×0.79 in |
| Electrical connection | Bayonet DIN 72 585 A1-3.1-Sn/K1 |
| Exhaust | Flap |
| Max. operating pressure | 159.5 psi |
| Mounting | 2x Ø 8.5 mm |
| Port thread 1 | M22 x 1.5 JED-388-0 |
| Port thread 2 | M22 x 1.5 JED – 388-0 |
| Protection class | IP 67 / IP 69K EN 60529 / IEC 529 |
| Rated current | 2220 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 12 V |
| GTIN | 04057875319245 |
| Size (mm x mm x mm) | 59 x 106 x 119 |
| UPC | 193133311966 |
| Weight (lb) | 1.508 |
| Weight (kg) | 0.684 |
| Brand | WABCO |
