Additional information
| Weight | 0,166 kg |
|---|---|
| Reference number | A0005436285, 0005436285 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.25155 |
| Cooling | Air |
| Distance between holes | 1.42×1.65 in |
| Electrical connection | Bayonet DIN 72 585 A2-2.1-Sn/K1 |
| Exhaust | 1.2 mm |
| Max. operating pressure | 188.55 psi |
| Mounting | 4x 6.5 mm |
| Multi Nominal diameter (From Port 1 to x) | 0.03 in |
| Port thread 1 | 0.024 in |
| Port thread 2 | 0.04 in |
| Protection class | IP 66 A / IP 68 |
| Rated current | 600 mA |
| Stroke | 0.03 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Type | Normally Closed |
| GTIN | 04057875184430 |
| Size (mm x mm x mm) | 65 x 90 x 43 |
| UPC | 193133263524 |
| Weight (kg) | 0.166 |
| Weight (lb) | 0.36597 |
| Voltage | 24 V |
| Brand | WABCO |
