Additional information
| Weight | 9,7 kg |
|---|---|
| Reference number | A0031315001, S411-141-640-0, 0031315001, A0031315001, A003131500180, S4111416400, S411-141-640-0 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 5.8291 |
| Comments | Flange with 2x M10 threads found behind crankcase, with holes 82mm from central line, and 55 mm from side to side |
| Cooling | Air |
| Crankshaft thread | M18 x 1.5 |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 261.1 psi |
| Mounting | Foot mounting |
| Operating speed | 3000 (1/min) |
| Piston diameter | 2.95 in |
| Piston stroke | 1.42 in |
| Port thread 0 | M26 x 1.5 |
| Port thread 2 | M26 x 1.5 |
| Port thread 8.1 | M10 x 1 |
| Port thread 8.2 | M22 x 1.5 |
| Swept volume (cm³) | 159 cm<sup>3</sup> |
| Technical specification | OE specification |
| Type of operation | High pressure using unloader |
| GTIN | 04057875155379 |
| Size (mm x mm x mm) | 253 x 180 x 128 |
| UPC | 193133435921 |
| Weight (kg) | 9.7 |
| Weight (lb) | 21.385 |
| Type | Single Cylinder |
| Brand | WABCO |
