Additional information
| Weight | 14,735 kg |
|---|---|
| Reference number | A4571306715, A4571304415, TDAS4123520260, S4123520260, 10127007, 4571302415, 8235-S4123520260, 6300-4123520260, 4571304415, A4571304415, 4571302415, A4571302415, A4571306715, S4123520260, S4123520260, TDAS4123520260, WAB4123520260 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 22.7683 |
| Cooling | Water |
| Crankshaft thread | M20 x 1.5 LH |
| Important information | When replacing this compressor a new flange gasket is required. Flange gasket 9121101404 to be bought separately |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 181.3 psi |
| Mounting | Mounting Flange |
| Operating speed | 3000 (1/min) |
| Piston diameter | 3.35 in |
| Piston stroke | 2.44 in |
| Port thread 0 | M30 x 1.5 |
| Port thread 2 | M26 x 1.5 |
| Port thread 21 | M26 x 1.5 (Closed) |
| Port thread 22 | M26 x 1.5 |
| Port thread 4 | M12 x 1.5 |
| Port thread 8.1 | Ø 0.16 in |
| Port thread 9 | M12 x 1.5 |
| Port thread 9.1 | M16 x 1.5 |
| Port thread 9.2 | M16 x 1.5 |
| Swept volume (cm³) | 352 cm<sup>3</sup> |
| Technical specification | OE specification |
| Type | Single Cylinder |
| Type of operation | Normal pressure using unloader |
| GTIN | 7895851063853 |
| Size (mm x mm x mm) | 345 x 197 x 335 |
| UPC | 193133436058 |
| Weight (kg) | 14.735 |
| Weight (lb) | 32.4851 |
| Port thread 8.2 | Ø 15.5 mm |
| Brand | WABCO |
