Additional information
| Weight | 14,15 kg |
|---|---|
| Reference number | S4123520270, A4571304515, 4571302315, A4571302315, 4571302615, A4571302615, 4571304515, S4123520270, 1528749, S4123520270 |
| Brand | ZF REMAN – WABCO |
| Part type | Remanufactured |
| Product category | Device |
| Calculated Volume (dm³) | 22.4 |
| Cooling | Water |
| Crankshaft thread | M20 x 1.5 |
| Important information | When replacing this compressor a new flange gasket is required. Flange gasket 9121101404 to be bought separately |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 181.3 psi |
| Mounting | Mounting Flange |
| Operating speed | 3000 (1/min) |
| Piston diameter | 3.35 in |
| Piston stroke | 2.44 in |
| Port thread 0 | M30 x 1.5 |
| Port thread 2 | M26 x 1.5 |
| Port thread 4 | M12 x 1.5 |
| Port thread 8.1 | Ø 0.16 in |
| Port thread 8.2 | Ø 0.62 in |
| Port thread 9 | M12 x 1.5 |
| Port thread 9.2 | M16 x 1.5 |
| Swept volume (cm³) | 352 cm<sup>3</sup> |
| Technical specification | OE specification |
| Type | Single Cylinder |
| Type of operation | Normal pressure using unloader |
| GTIN | 04057875322467 |
| Size (mm x mm x mm) | 350 x 200 x 320 |
| UPC | 193133234975 |
| Weight (kg) | 14.15 |
| Weight (lb) | 31.2 |
| Port thread 9.1 | M16 x 1.5 |
| Brand | WABCO |
