Additional information
| Weight | 12,947 kg |
|---|---|
| Reference number | 9061305815, A9061305415, 9061304115, 9061305415, 9061305815, 9504985 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 15.485 |
| Cooling | Water |
| Crankshaft thread | M20 x 1.5 LH |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 181.3 psi |
| Mounting | Mounting Flange |
| Operating speed | 3000 (1/min) |
| Piston diameter | 3.35 in |
| Piston stroke | 1.65 in |
| Port thread 0 | 1.18 in |
| Port thread 2 | M26 x 1.5 |
| Port thread 8.1 | Ø 0.24 in |
| Port thread 9.1 | M14 x 1.5 |
| Port thread 9.2 | M14 x 1.5 |
| Swept volume (cm³) | 238 cm<sup>3</sup> |
| Technical specification | OE specification |
| Type of operation | Normal pressure using unloader |
| GTIN | 7895851076389 |
| Size (mm x mm x mm) | 231 x 205 x 327 |
| UPC | 193133436010 |
| Weight (kg) | 12.947 |
| Weight (lb) | 28.5432 |
| Type | Single Cylinder |
| Brand | WABCO |
