Additional information
| Weight | 4,016 kg |
|---|---|
| Reference number | AB9324000060, 1526796, 1518168, 1505119, 1506409, 1506410, 1519202R, A0004301215, A0004301315, A0004302915, A0004303015, A0004309815, S9324000240, 0004301215, A0004301215, 0004301315, 0014319215, A0004301315, 0004302915, A0004302915, 0004303015, A0004303015, 0004309815, A0004309815, S9324000240, 1505119, S9324000240 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 9.661 |
| Cartridge type | Desiccant Cartridge |
| Cut-out pressure | 174 psi |
| Exhaust | JED-463-1 |
| Heating connection | Bayonet DIN 72585-A1-2.1-1-Sn/K2 |
| Max. operating pressure | 188.5 psi |
| Opening pressure | 210.31 psi |
| Operating pressure | 188.5 psi |
| Operational range | 21.76 psi |
| Port thread 11 | M22 x 1.5 |
| Port thread 12 | M12 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M16 x 1.5 JED – 388 |
| Port thread 23 | Tire inflation device M16 x 1.5 |
| Port thread 24 | M22 x 1.5 JED – 388 |
| Port thread 3 | JED-463-1 |
| Silencer | No (432 407 015 0 retrofittable) |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Unloader | Yes |
| Voltage | 24 V |
| GTIN | 7895851067936 |
| Size (mm x mm x mm) | 272 x 192 x 185 |
| UPC | 193133448273 |
| Weight (kg) | 4.016 |
| Weight (lb) | 8.8538 |
| Port thread 4/23 | 1/4" – 18 NPTF |
| Brand | WABCO |
