Additional information
| Weight | 4 kg |
|---|---|
| Reference number | 1517967, 81521026105, 81521026024, 81521026097, 81521026020, 81521026022, 81521026037, 81521026046, 81521026047, 81521026055, 81521026058, 81521026060, 81521026061, 81521026101, 81521026102, 81521026105, 81521026107, 81521026109, 81521026220, 81521026318, 81521026097, 81521026105, 1517967 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Calculated Volume (dm³) | 12.35 |
| Cartridge type | Desiccant Cartridge |
| Cut-out pressure | 181.30±4.35 psi |
| Exhaust | JED-463-1 |
| Heater | PRO 410 920 2 |
| Important information | Compatible with Provia heater only. |
| Max. operating pressure | 188.5 psi |
| Operational range | 21.76±7.25 psi |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 3 | JED-463-1 |
| Port thread 4/23 | 1/4" – 18 NPTF |
| Ports | 1, 21: M22 x 1.5; 22: M16 × 1.5 |
| ProVia warranty | 1 year |
| Technical specification | AM specification |
| Temperature range | -40°C to +65°C |
| Size (mm x mm x mm) | 280 x 210 x 210 |
| UPC | 193134005086 |
| Weight (kg) | 4 |
| Weight (lb) | 8.818 |
| GTIN | 04057877002794 |
| Brand | WABCO |
