Additional information
| Weight | 1,582 kg |
|---|---|
| Reference number | 1519361, 7420933629, 20857304, 2107433, 20857304, 2107433, 7420933629 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 6.0428 |
| Distance between holes | 4.33 in |
| Important information | Please follow the installation instructions of the vehicle manufacturer |
| Length | 318 mm |
| Max. operating pressure | 145.0 psi |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 4x Ø 9.0 mm |
| Port thread 11 | 2000 – 1/2" |
| Port thread 12 | 2000 – 3/8" |
| Port thread 22 | 2000 – 3/8" |
| Port thread 31 | 2000-1/2" |
| Port thread 32 | Ø 8.0 mm |
| Port thread 33 | Ø 11.0 mm |
| Push-rod thread | Ball Ø 12.0 mm |
| Stroke | 3.35 in |
| Technical specification | OE specification |
| GTIN | 7895851086739 |
| Size (mm x mm x mm) | 124 x 393 x 124 |
| UPC | 193133374145 |
| Weight (kg) | 1.582 |
| Weight (lb) | 3.4877 |
| Temperature range | -30°C to +100°C |
| Brand | WABCO |
