Additional information
| Weight | 2,808 kg |
|---|---|
| Reference number | 1425316202002, 1,42532E+12, S31A0E0740, 16WY104010, 16WY1-04010, WG97192300251, 160400210, 1604-00210 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 7.067 |
| Distance between holes | 5.12 in |
| Important information | Please follow the installation instructions of the vehicle manufacturer |
| Length | 330 mm |
| Max. operating pressure | 145.0 psi |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 4x Ø 9.0 mm |
| Port thread 1-4 | M14 x 1.5 |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M12 x 1.5 JED – 464 |
| Port thread 22 | M12 x 1.5 JED – 464 |
| Port thread 31 | Flap Exhaust |
| Port thread 32 | Ø 8.0 mm |
| Push-rod thread | Ball Ø 12.0 mm |
| Stroke | 0.98 in |
| Technical specification | OE specification |
| GTIN | 7895851075955 |
| Size (mm x mm x mm) | 410 x 139 x 124 |
| UPC | 193133372974 |
| Weight (kg) | 2.808 |
| Weight (lb) | 6.1906 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
