Additional information
| Weight | 2,5 kg |
|---|---|
| Reference number | 659826, 6573091, 1506467, 160230576A, 1602305-76A, 1612516205010, S31A0E0720, 5010556022, 5010556022, W20803.02800.01W, S9700514240, 16MC104010, 216500050, 16MC1-04010, 8235-S9700514240, N2307160011, S9700514240, 1506467, S9700514240, 1935602, SWB563050017, 10709118, 160400213, 1604-00213 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 7.247 |
| Comments | ZF-FO |
| Distance between holes | 5.12 in |
| Important information | Please follow the installation instructions of the vehicle manufacturer |
| Length | 391 mm |
| Max. operating pressure | 145.0 psi |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 4x Ø 9.0 mm |
| Port thread 1-4 | M14 x 1.5 ( B ) |
| Port thread 11 | M16 x 1.5 JED – 464 |
| Port thread 31 | Flap Exhaust |
| Port thread 32 | Ø 8.0 mm |
| Push-rod thread | Ball Ø 12.0 mm |
| Stroke | 3.35 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Size (mm x mm x mm) | 395 x 139 x 132 |
| UPC | 193133449690 |
| Weight (kg) | 2.5 |
| Weight (lb) | 5.5116 |
| GTIN | 7895851083455 |
| Brand | WABCO |
