Additional information
| Weight | 3,004 kg |
|---|---|
| Reference number | 3842957018, A3842957018, 0002952118 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 4.601 |
| Distance between holes | 5.12 in |
| Important information | Please follow the installation instructions of the vehicle manufacturer |
| Length | 278 mm |
| Max. operating pressure | 145.0 psi |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 4x Ø 9.0 mm |
| Port thread 1-4 | M14 x 1.5 ( K ) |
| Port thread 11 | M16 x 1.5 |
| Port thread 31 | Flap Exhaust |
| Port thread 32 | Ø 8.0 mm |
| Push-rod thread | Ball Ø 12.0 mm |
| Stroke | 2.30 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 7895851022898 |
| UPC | 193133373407 |
| Weight (kg) | 3.004 |
| Weight (lb) | 6.6227 |
| Size (mm x mm x mm) | 290 x 123 x 129 |
| Brand | WABCO |
