Additional information
| Weight | 3,402 kg |
|---|---|
| Reference number | 1518251, 1518248, 1197265, 99707308039, 81307256053, 81307256054, 81307256055, 81307259054, 1197265, 81307256031, 81307256032, 81307256063, 81307256054, 10772982 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 6.485 |
| Comments | MAN |
| Distance between holes | 5.12 in |
| Important information | Please follow the installation instructions of the vehicle manufacturer |
| Length | 400 mm |
| Max. operating pressure | 145.0 psi |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 4x Ø 9.0 mm |
| Port thread 1-4 | M14 x 1.5 ( K ) |
| Port thread 11 | M16 x 1.5 |
| Port thread 31 | Flap Exhaust |
| Port thread 32 | Ø 8.0 mm |
| Push-rod thread | Ball Ø 12.0 mm |
| Stroke | 3.35 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Size (mm x mm x mm) | 399 x 126 x 129 |
| UPC | 193133373223 |
| Weight (kg) | 3.402 |
| Weight (lb) | 7.5001 |
| GTIN | 7895851040250 |
| Brand | WABCO |
