Additional information
| Weight | 0,781 kg |
|---|---|
| Reference number | 280622, 387819, 1519317, 8283112000, 8285112000, 82851120000, Q8285112000, 2103007, 20281, 81251506011, 81521166043, 81521166053, 81521166056, 81521166057, 81521166066, 81521506011, Q8285112000, 110242400, 1102422543402, 81521506011, 79200360048, 99100360074 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.0976 |
| Exhaust | Snap on contour JED – 463 |
| Max. operating pressure | 145.04 psi |
| Mounting | 4x M8 |
| Opening pressure | 4.35 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | 2x M16 x 1.5 |
| Port thread 3 | M22 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Regulating ratio | 1:1 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Version | Pressure reduction |
| GTIN | 04057875302742 |
| Size (mm x mm x mm) | 96 x 103 x 111 |
| Weight (kg) | 0.781 |
| Brand | WABCO |
