Additional information
| Weight | 2,2 kg |
|---|---|
| Reference number | A0064290244, 64290244 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Calculated Volume (dm³) | 7.65 |
| Distance between bolts | 3.94×2.52 in |
| Electrical connection | Bayonet (DIN 72585) |
| Max. operating pressure | 181.30 psi |
| Mounting | 3x M8 |
| Port thread 1 | M22 x 1.5 JED-388-4 |
| Port thread 21 | M22 x 1.5 JED – 388-4 |
| Port thread 22 | M22 x 1.5 JED – 388-4 |
| Port thread 3 | Silencer |
| Port thread 4 | M16 x 1.5 JED – 388-4 |
| ProVia warranty | 1 year |
| Protection class | IP 6K6K / IP 6K9K |
| Rated current | 1400 mA |
| Silencer | 4324070500 |
| Technical specification | AM specification |
| Temperature range | -40°F to +176°F |
| GTIN | 04057877044671 |
| Size (mm x mm x mm) | 250 x 170 x 180 |
| UPC | 193134009510 |
| Weight (kg) | 2.2 |
| Weight (lb) | 4.85 |
| Voltage | 24 V |
| Brand | WABCO |
