Additional information
| Weight | 0,86 kg |
|---|---|
| Reference number | 1302103, 5010207451, A0054291044, 13C2508396AA |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Calculated Volume (dm³) | 2.356 |
| Max. operating pressure | 145.0 psi |
| Operating pressure | 188.5 psi |
| Port thread 1 | M22 x 1.5 VOSS |
| Port thread 21 | M22 x 1.5 Voss |
| Port thread 22 | M22 x 1.5 Voss |
| Port thread 41 | M16 x 1.5 JED -388- VOSS connection |
| Port thread 42 | M16 x 1.5 JED -388- VOSS connection |
| ProVia warranty | 1 year |
| Response pressure | 0.3 bar |
| Silencer | Yes |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057877023669 |
| Size (mm x mm x mm) | 130 x 145 x 125 |
| UPC | 193134006724 |
| Weight (lb) | 1.896 |
| Weight (kg) | 0.86 |
| Brand | WABCO |
