Additional information
| Weight | 1,355 kg |
|---|---|
| Reference number | 87019852, 1519311R, 1519312, 1519313R, 1519310, 8143073, 10549, 11609, 011609, TDAS9710027000, 163413, DC54371, 2101008, S9710027000, 8283884000, 1133363, 502814801, 6300-9710027000, S9710027000, 1519312, S9710027000, 2090080, 2090081, 1935619, 1935620, 2090079, 1060752, 8283884000, 53355, INS0120001, 053355, 32939, 10558850, WA9710027017, WAB9710027000, WA9710027007, 1012005 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 3.095 |
| Comments | Combination of 9710020200 and release valve 9630010130 |
| Distance between holes | 2.8 in |
| Max. operating pressure | 1.0 MPa |
| Mounting | 2x Ø 11.0 mm |
| Port thread 1 | M22 x 1.5 JED-152 |
| Port thread 12 | M22 x 1.5 JED-152 |
| Port thread 2 | 3x M16 x 1.5 JED-152 |
| Port thread 3 | Silencer |
| Port thread 4 | M16 x 1.5 JED-152 |
| Predominance | 0 |
| Range of adjustment | 0.07 Mpa |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Type | With brake valve and Release valve |
| GTIN | 04057876223305 |
| UPC | 193133534624 |
| Weight (kg) | 1.355 |
| Weight (lb) | 2.987 |
| Size (mm x mm x mm) | 169 x 110 x 166.5 |
| Brand | WABCO |
