Additional information
| Weight | 1,403 kg |
|---|---|
| Reference number | 9512544, 1325334R, 1360073, 1519304R, 1325334, 1325333R, 1325333, 815809, 815808, 1519305, 8998014, 8283884000, 82838840000, 8285135000, 8283793000, 5153, 001523, 006680, A74944M03A01, ASX0571002, 150868, AZ51634, 2101007, S9710025310, 945018, 9453390, 500945018, 82838840000, 65022370, 79312, 76312, 307684, 1200007, 1133361, 502993301, S9710025310, 07115000, 07111000, 49500111001, 1325333R, S9710025310, 5000809875, 1935618, 2090073, 1935617, 2090072, 1021173, 050021, 050787, 82838840000, 50021, T2004491, 30892, 32413540, 637206520, 637206720, WA9710025337, WA9710025317 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 3.165 |
| Comments | Combination of 9710020300 and release valve 9630010130 |
| Distance between holes | 2.8 in |
| Max. operating pressure | 1.0 MPa |
| Mounting | 2x Ø 11.0 mm |
| Port thread 1 | M22 x 1.5 JED-152 |
| Port thread 12 | M22 x 1.5 JED-152 |
| Port thread 2 | 2x M16 x 1.5 JED-152 / 1x Flange M16 x 1.5 JED-152 |
| Port thread 3 | Silencer |
| Port thread 4 | M16 x 1.5 JED-152 |
| Predominance | 0 |
| Range of adjustment | 0.07 Mpa |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Type | Only Emergency valve |
| GTIN | 04057876222704 |
| UPC | 193133534716 |
| Weight (kg) | 1.403 |
| Weight (lb) | 3.093 |
| Size (mm x mm x mm) | 167 x 162 x 117 |
| Brand | WABCO |
