Additional information
| Weight | 0,92 kg |
|---|---|
| Reference number | 605251000, 0720185, 8283979000, A0004312213, A71519M70A10, 03425120, 2101001, S4710030200, 49033840, 1111344, 315962, 720185, 2S4710030200, 2S471 003 020 0, 6300-4710030200, 81523019078, 4710030200, 0004312213, A0004312213, S4710030200, 308030, 3532, S4710030200, 5000100598, 202053, 2090048, 08726200, 49033840, WAB4710030200 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.6535 |
| Distance between holes | 2.8 in |
| Max. operating pressure | 76.87 psi |
| Mounting | 2x Ø 10.5 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 12 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port thread 3 | Flap Exhaust |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Only Emergency valve |
| GTIN | 7895851056084 |
| Size (mm x mm x mm) | 112 x 133 x 111 |
| UPC | 193133442905 |
| Weight (kg) | 0.92 |
| Weight (lb) | 2 |
| Brand | WABCO |
