Additional information
| Weight | 1,413 kg |
|---|---|
| Reference number | H03140201, 0830550R, 1506472R, 1519298R, 0816370, 1518257, 0830550, 830550, 1506643, 0925, 006705, TDAS9710021500, CF351407, CF351054, AJU7602, H03140201, H031402, 5311-070-01, 201993, 200291, 9710020000, 9710021500, 500005829, 09988413, 500005829, 101750, 2480005, WZ2480005, 2101004, S971-002-150-0, 58106060, 505810606, 5810606, 79310, 1133358, 4110191, 4110321, 830550, 10170952, 10170852, A05020306, A05020403, 8235-S9710021500, 6300-9710021500, 0005663802, N2523019016, 82580000060, S9710021500, 07110000, 309044, 49500111000, 0830550R, 0865625R, 1518257, 1506643, S971-002-150-0, 5021170445, AG46729002, 5021170441, 5021170440, 5021170439, 1108600, 0001108600, 1738443, 579009, 0579009, 1738441, 2090062, 2090064, 1021172, 9710020000, 050005, 9710021500, 54354, 054354, 4631, 637206780, 3570408, WAB9710021500, WA9710021507, 11018647 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 3.308 |
| Distance between holes | 2.8 Inch |
| Max. operating pressure | 1.0 MPa |
| Mounting | 2x Ø 11.0 mm |
| Port thread 1 | M22 x 1.5 JED-152 |
| Port thread 12 | Ø 15×1.5 |
| Port thread 2 | 3x Ø 10×1 / 1x Flange M16 x 1.5 JED-152 |
| Port thread 3 | Silencer |
| Port thread 4 | Ø 8×1 |
| Predominance | 0 |
| Range of adjustment | 0.07 Mpa |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Type | Only Emergency valve |
| GTIN | 04057876223367 |
| Size (mm x mm x mm) | 170 x 139 x 140 |
| Weight (kg) | 1.413 |
| Weight (lb) | 3.115 |
| UPC | 193133534723 |
| Brand | WABCO |
