Additional information
| Weight | 1,669 kg |
|---|---|
| Reference number | 1506649, 1528886, 5010260496 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 2.9352 |
| Charging pressure | 54.39 psi |
| Closing pressure static 21 | 65.3 psi |
| Closing pressure static 22 | 65.3 psi |
| Closing pressure static 23 | 65.3 psi |
| Closing pressure static 24 | 65.3 psi |
| Comments | Renault |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 101.53 psi |
| Opening pressure 22 | 101.53 psi |
| Opening pressure 23 | 108.78 psi |
| Opening pressure 24 | 101.53 psi |
| Opening pressure circuit 1+2 | 7.5 + 7.0 bar |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M22 x 1.5 |
| Port thread 24 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Pressure sensor | No |
| Technical specification | OE specification |
| Temperature range | -40°C to +90°C |
| Type | dynamic |
| GTIN | 04057875290858 |
| Size (mm x mm x mm) | 187 x 144 x 109 |
| UPC | 193133363149 |
| Weight (kg) | 1.669 |
| Weight (lb) | 3.6795 |
| Port thread 23 | M22 x 1.5 |
| Brand | WABCO |
