Additional information
| Weight | 0,68 kg |
|---|---|
| Reference number | 657367, 1505404, 1505404 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.87437 |
| Charging pressure | 61.64 psi |
| Closing pressure dynamic 21 | 72.5 psi |
| Closing pressure dynamic 22 | 72.5 psi |
| Closing pressure dynamic 23 | 72.5 psi |
| Closing pressure dynamic 24 | 72.5 psi |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 116.03 psi |
| Opening pressure 22 | 116.03 psi |
| Opening pressure 23 | 123.28 psi |
| Opening pressure 24 | 116.03 psi |
| Opening pressure circuit 1+2 | 7.2 + 6.5 bar |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Pressure sensor | No |
| Technical specification | OE specification |
| Temperature range | -45°C to +90°C |
| Type | dynamic |
| GTIN | 04057875290704 |
| Size (mm x mm x mm) | 92 x 108 x 88 |
| UPC | 193133362920 |
| Weight (kg) | 0.68 |
| Weight (lb) | 1.4991 |
| Port thread 24 | M16 x 1.5 |
| Brand | WABCO |
