Additional information
| Weight | 0,678 kg |
|---|---|
| Reference number | 656249, 3454402120, 34544 02120, 1505403, A0034316906, TDAS9347141250, S9347141250, 502666608, F00271322, 6300-9347141250, ZG046450002, A0034316906, 0034316906, S9347141250, 13C2508165AA, 1505403, S9347141250, WAB9347141250 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.8514 |
| Charging pressure | 54.39 psi |
| Closing pressure dynamic 21 | 72.5 psi |
| Closing pressure dynamic 22 | 72.5 psi |
| Closing pressure dynamic 23 | 72.5 psi |
| Closing pressure dynamic 24 | 72.5 psi |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 101.53 psi |
| Opening pressure 22 | 101.53 psi |
| Opening pressure 23 | 108.78 psi |
| Opening pressure 24 | 101.53 psi |
| Opening pressure circuit 1+2 | 6.2 + 6.2 bar |
| Port thread 1 | 1/2" – 14 Dry Seal PTF |
| Port thread 21 | 3/8" – 18 Dry Seal NPTF |
| Port thread 22 | 3/8" – 18 Dry Seal PTF |
| Port thread 23 | 3/8" – 18 Dry Seal PTF |
| Port thread 4 | 3/8" – 18 Dryseal PTF |
| Pressure sensor | No |
| Technical specification | OE specification |
| Temperature range | -40°C to +90°C |
| Type | dynamic |
| GTIN | 04057875290735 |
| Size (mm x mm x mm) | 110 x 90 x 86 |
| UPC | 193133448624 |
| Weight (kg) | 0.678 |
| Weight (lb) | 1.4947 |
| Port thread 24 | M16 x 1.5 |
| Brand | WABCO |
