Additional information
| Weight | 0,994 kg |
|---|---|
| Reference number | 1518174, 99708410131, 04456608, 02494268, 04720938, 098235373AS, 35373, 72740, 81521516013, 81521516057, 81521516066, 81521516081, 81521516092, 0014312306, 81521516013, 96044400 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.3131 |
| Charging pressure | 50.76 psi |
| Closing pressure dynamic 21 | 94.3 psi |
| Closing pressure dynamic 22 | 94.3 psi |
| Closing pressure dynamic 23 | 82.7 psi |
| Closing pressure dynamic 24 | 82.7 psi |
| Max. operating pressure | 145.0 psi |
| Opening pressure 21 | 101.53 psi |
| Opening pressure 22 | 101.53 psi |
| Opening pressure 23 | 94.27 psi |
| Opening pressure 24 | 94.27 psi |
| Opening pressure circuit 1+2 | 6.5 + 6.5 bar |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Pressure sensor | No |
| Technical specification | OE specification |
| Temperature range | -40°C to +90°C |
| Type | dynamic |
| GTIN | 04057875289906 |
| Size (mm x mm x mm) | 140 x 113 x 83 |
| UPC | 193133361954 |
| Weight (kg) | 0.994 |
| Weight (lb) | 2.1914 |
| Port thread 24 | M16 x 1.5 |
| Brand | WABCO |
