Additional information
| Weight | 0,686 kg |
|---|---|
| Reference number | G931882020010, 109 254 330 0, 3515ADY-010, 1518192, 9347141230, 35CR315010, 235500063, ACHE908, 20240887, 240887, 3515-00042A, 3515-00042, 3553-10-00002 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.863 |
| Charging pressure | 52.21 psi |
| Closing pressure dynamic 21 | 72.5 psi |
| Closing pressure dynamic 22 | 72.5 psi |
| Closing pressure dynamic 23 | 72.5 psi |
| Closing pressure dynamic 24 | 72.5 psi |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 100.08 psi |
| Opening pressure 22 | 100.08 psi |
| Opening pressure 23 | 104.43 psi |
| Opening pressure 24 | 104.43 psi |
| Opening pressure circuit 1+2 | 8.5 + 8.0 bar |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Pressure sensor | No |
| Technical specification | OE specification |
| Temperature range | -40°C to +90°C |
| Type | dynamic |
| GTIN | 04057875290674 |
| Size (mm x mm x mm) | 109 x 90 x 88 |
| UPC | 193133362951 |
| Weight (kg) | 0.686 |
| Weight (lb) | 1.5124 |
| Port thread 24 | M16 x 1.5 |
| Brand | WABCO |
