Additional information
| Weight | 0,7 kg |
|---|---|
| Reference number | 1519373, 81521516093, 81521519093, 81521516096, 81521516093, 1935512 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.795 |
| Charging pressure | 50.76 psi |
| Closing pressure dynamic 21 | 92.8 psi |
| Closing pressure dynamic 22 | 72.5 psi |
| Closing pressure dynamic 23 | 72.5 psi |
| Closing pressure dynamic 24 | 72.5 psi |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 100.08 psi |
| Opening pressure 22 | 100.08 psi |
| Opening pressure 23 | 101.53 psi |
| Opening pressure 24 | 100.08 psi |
| Opening pressure circuit 1+2 | 7.0 + 6.9 bar |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Pressure sensor | No |
| Technical specification | OE specification |
| Temperature range | -40°C to +90°C |
| GTIN | 04057875290667 |
| Size (mm x mm x mm) | 90 x 109 x 81 |
| UPC | 193133362906 |
| Weight (kg) | 0.7 |
| Weight (lb) | 1.543 |
| Port thread 24 | M16 x 1.5 |
| Brand | WABCO |
