Additional information
| Weight | 0,687 kg |
|---|---|
| Reference number | 1519213, 98413416, 161507, 42544391, 98400429, 99480157, A05021247, 20252278 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.94468 |
| Charging pressure | 54.39 psi |
| Closing pressure dynamic 21 | 72.5 psi |
| Closing pressure dynamic 22 | 72.5 psi |
| Closing pressure dynamic 23 | 72.5 psi |
| Closing pressure dynamic 24 | 72.5 psi |
| Max. operating pressure | 188.5 psi |
| Opening pressure circuit 1+2 | 7.0 + 6.9 bar |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Port thread 24 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Pressure sensor | No |
| Technical specification | OE specification |
| Type | static |
| GTIN | 7895851076938 |
| Size (mm x mm x mm) | 113 x 95 x 88 |
| UPC | 193133362463 |
| Weight (kg) | 0.687 |
| Weight (lb) | 1.5146 |
| Temperature range | -40°C to +90°C |
| Brand | WABCO |
